20A RCCB Circuit Breaker 4 Pole Earth Leakage Circuit Breaker G Type

Ask Lasest Price
Brand Name :	SEFIE
Model Number :	SFL5-63
Certification :	IEC60898,CB,CE
Price :	Negotiable
Supply Ability :	200000pcs per month
Delivery Time :	14 days after receipt of deposit
Payment Terms :	L/C, T/T

Add to Cart

Product Details
Company Profile

20A RCCB Circuit Breaker 4 Pole Earth Leakage Circuit Breaker G Type

SFL5-63 series Residual Current Device Earth Leakage 2P,4P ,16A ,20A ,25A , 32A , 40A , 63A RCCB

The residual current device(RCD) works with no extra power supply to the operating mechanism. It compares the magnitude of the currents through the neutral and phase conductors. The conductors are coiled on toroid and together with the secondary winding form a measurement transformer. The power conductors are coiled in such a way that the magnetic fields generated at electrical current flow through them are mutually neutralized. At failure in the insulation of some of the conductors or at presence of a person under voltage, the system is misbalanced and the magnetic fields can not be neutralized. This residual field generates in the secondary current winding, called current leakage. The device breaks when the value of this current exceeds the limit value of the RCD. Every people from any profession and any cultural level are in close contact with electrical energy at any hour of the day and they may encounter residual currents. Under normal conditions, benefits from electrical energy are countless. However, damages arising from an insulation error are also really huge.

type	In/A	I△n/A	Residual Current (I△)Is Corresponding To The Following Breaking Time
type	In/A	I△n/A	I△n	2I△n	5I△n	5A ,10A ,20A ,50A ,100A ,200A ,500A
general type	any value	any value	0.3	0.15	0.04	0.04	Max Break-time
S type	≥25	＞0.03	0.5	0.2	0.15	0.15	Max Break-time
S type	≥25	＞0.03	0.13	0.06	0.05	0.04	Min non-driving time
G type	any value	any value	0.5	0.2	0.15	0.15	Max Break-time
G type	any value	any value	0.01	0.01	0.01	0.01	Min Non-driving time
The general type RCBO whose current I△n is 0.03mA or less can use 0.25A instead of 5I△n

Type	Tripping current I△/A
AC	0.5I△n＜I△＜I△n
A	Lagging Angle	I△n＞0.01A	I△n≤0.01A
	0	0.35I△n≤I△≤1.4I△n	0.35I△n≤I△n≤2I△n
	90	0.25I△n≤I△≤1.41I△n	0.25I△n≤I△≤2I△n
	135	0.11I△n≤I△≤1.4I△n	0.11I△n≤I△≤2I△n
